Anatomy Atlases: Atlas of Human Anatomy in Cross Section: Section 5. Lower Thorax (Lungs) and Abdomen

Atlas of Human Anatomy in Cross Section

Section 5. Lower Thorax (Lungs) and Abdomen

Ronald A. Bergman, Ph.D., Adel K. Afifi, M.D., Jean J. Jew, M.D., and Paul C. Reimann, B.S.
Peer Review Status: Externally Peer Reviewed


Key Figure 5a
Key Figure 5b
Key Figure 5c
Key Figure 5d
Key Figure 5e

Key Figure 5d

1. Vertebral a.
2. Right common carotid a.
3. Transverse cervical a.
4. Suprascapular a.
5. Internal jugular v.
6. Subclavian v.
7. Axillary v.
8. Internal thoracic a.
9. Brachiocephalic v.
10. Pulmonary a.
11. Superior vena cava
12. Right coronary a.
13. Left coronary a.
14. Right ventricle
15. Hepatic w.
16. Thoracic aorta
17. Splenic o. and v.
18. Portal v.
19. Celiac a.
20. Renal v.
21. Inferior vena cava
22. Abdominal aorta
23. Iliohypogastric nerve
24. Ilioinguinal nerve
25. Superior mesenteric v.
26. Subcostal nerve
27. Jejunal AA.
28. Lumbar nerves, 11, 111, IV
29. Common iliac a.
30. Common iliac v.
31. Internal iliac a.
32. Lateral cutaneous nerve of the thigh
33. External iliac a.
34. Obturator nerve
35. Pudendal nerve
36. Sciatic nerve
37. Saphenous v.
38. Femoral v.
39. Femoral a.

Modified from Eycleshmer AC, Shoemaker DM. A cross-section anatomy. New York: D Appleton and Company 1911.

Plates
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
5.9
5.10
5.11
5.12
5.13
5.14
5.15
